Achilles tendonitis exercises: eccentric heel drops for Achilles tendon pain

The main eccentric exercise for Achilles tendon pain is the heel drop: rise on both feet on a step, shift to the sore leg, and lower slowly over three seconds until the heel sinks below the edge. The original protocol was 3 x 15, twice a day, with straight and bent knee; Walkito starts at 3 x 10, each leg. If the pain is right at the heel bone, do the drops at floor level instead.

The 2024 clinical guideline grades tendon-loading exercise A, its top grade, and a 2021 network meta-analysis of 29 trials found no single protocol clearly better than another. What matters is loading the tendon steadily for weeks. "Tendonitis" and "tendinopathy" mean the same problem here; the name does not change the exercises. Pain under the foot rather than at the back of the heel? See plantar fasciitis vs Achilles tendonitis.

How do you do eccentric heel drops for Achilles tendon pain?

The eccentric heel drop is a strength exercise, not a stretch. You rise on both feet, shift to the painful side, and lower slowly on one foot, letting the heel sink below the step edge. The lowering phase is the eccentric contraction: the calf muscle lengthening under load. That controlled descent is what builds tendon capacity over weeks.

The most common mistake is holding the bottom position like a calf stretch. That turns it into a static stretch, which is a different stimulus. The point is the slow, loaded descent. Three seconds down, with the muscle working the whole way, then both feet to come back up.

The 1998 Alfredson trial had 15 athletes with long-standing mid-tendon Achilles pain do eccentric heel drops twice a day, 7 days a week, for three months, straight and bent knee. All 15 returned to their prior running level. A small trial with no control group, but it launched a whole line of research.

Eccentric heel drops (straight knee). A figure on a step lowering one heel below the step edge with a straight knee, the calf and Achilles highlighted
Drawing of the same move, with the working area highlighted
Eccentric heel drop: up on both feet, down slowly on one, heel below the step

Eccentric heel drops (straight knee)

In the exercise library: Eccentric heel drops

Stand on a step edge. Rise on both feet, shift to the painful leg, lower slowly over three seconds. Heel sinks below the step. Both feet to come back up. Straight knee targets the gastrocnemius, the bigger, more superficial calf muscle. For insertional pain, lower only to floor level.

Evidence: Strong. The original Alfredson protocol; supported by the 2024 guideline grading exercise A.

Pain above 5/10 that does not settle by the next morning, or pain worsening week over week

Alfredson H, Pietilä T, Jonsson P, Lorentzon R. Heavy-load eccentric calf muscle training for the treatment of chronic Achilles tendinosis. American Journal of Sports Medicine. 1998;26(3):360–366.

Chimenti RL, Neville C, Houck J, Cuddeford T, Carreira D, Martin RL. Achilles Pain, Stiffness, and Muscle Power Deficits: Midportion Achilles Tendinopathy Revision 2024. Journal of Orthopaedic & Sports Physical Therapy. 2024;54(12):CPG1–CPG32.

Jonsson P, Alfredson H, Sunding K, Fahlström M, Cook J. New regimen for eccentric calf-muscle training in patients with chronic insertional Achilles tendinopathy: results of a pilot study. British Journal of Sports Medicine. 2008;42(9):746–749.

Which Achilles exercises lead up to heel drops, and how much?

If heel drops hurt too much to start, build up from seated raises. Move up a step once two sessions at the current level felt easy. These are Walkito's starting doses next to the research protocols. How these guides are written.

Achilles tendonitis exercises: research doses and Walkito starting doses
ExerciseResearch protocol doseWalkito starting doseEvidence
Seated heel raisesSilbernagel Phase 1: 3 x 10, sitting3 x 10, both feetStrong: matches the published Phase 1 protocol
Double-leg heel raisesSilbernagel Phase 1: 3 x 10-15, standing3 x 10, both feetStrong: direct match to Phase 1
Heel raise hold (isometric)2024 guideline names isometric as effective; 3-5 x 30-45s suggested in practice3 x 20s, both feetModerate: guideline includes isometric loading; no isolated Achilles isometric-only RCT
Eccentric heel drops (straight knee)Alfredson: 3 x 15, 2x/day, 7 days/week, three months3 x 10, each legStrong: the original protocol; guideline grade A
Calf stretch (straight knee)Not part of loading trials; a mobility adjunct3 x 30s hold, each legEarly: framed as mobility, not as a loading exercise for Achilles
Soleus stretch (bent knee)Not part of loading trials; a mobility adjunct3 x 30s hold, each legEarly: same caveat; avoid deep stretching for insertional pain
Seated heel raises. A seated figure lifting both heels, the calves highlighted
Seated heel raises: press up through the balls of the feet, hands add load

Seated heel raises

In the exercise library: Calf raises

Sit with feet flat. Press up through the balls of both feet. Hands on the knees add resistance. A low-load way to start when standing work is too painful.

Evidence: Strong. Matches Silbernagel 2007 Phase 1 dose. Guideline grade A covers all tendon-loading types.

Pain above 5/10 that does not settle by the next morning

Double-leg heel raises. A standing figure rising onto the toes of both feet, the calves highlighted
Drawing of the same move, with the working area highlighted
Double-leg heel raises: rise straight up, then lower slowly

Double-leg heel raises

Stand on both feet, rise straight up over the big toes, lower slowly over three seconds. Both feet share the load.

Evidence: Strong. Direct match to Silbernagel 2007 Phase 1. Guideline grade A.

Pain above 5/10 that does not settle by the next morning

Heel raise hold (isometric). A figure holding a raised position on both feet, the calves highlighted
Drawing of the same move, with the working area highlighted
Heel raise hold: rise, then stay still at the top

Heel raise hold (isometric)

Rise onto your toes on both feet, hold still at the top. Do not sink down. The muscle works without moving, which loads the tendon without the up-and-down motion that early-stage Achilles pain can find provocative.

Evidence: Moderate. The 2024 guideline names isometric as one of the effective tendon-loading types. No isolated Achilles isometric RCT.

Pain above 5/10 that does not settle by the next morning

Calf stretch (straight knee). A figure leaning on a wall with the back leg straight and the calf highlighted
Drawing of the same move, with the working area highlighted
Calf stretch: back leg straight, heel down

Calf stretch (straight knee)

In the exercise library: Calf stretch (gastrocnemius, straight knee)

Hands on a wall. Back leg straight, heel down, hips forward. Do not bounce. For insertional pain, keep it gentle and stop if it provokes the attachment.

Evidence: Early. Not part of the Achilles loading trials. A mobility adjunct. Avoid deep stretching for insertional pain.

Any sharp pull at the heel-bone attachment

Soleus stretch (bent knee). A figure in a split stance with bent knees, the lower calf highlighted
Drawing of the same move, with the working area highlighted
Soleus stretch: bend the back knee until the stretch moves lower

Soleus stretch (bent knee)

In the exercise library: Soleus stretch (bent knee)

Same wall position, bend the back knee until the stretch moves lower, near the heel. The soleus only releases with the knee bent.

Evidence: Early. Not part of the Achilles loading trials. A mobility adjunct. Avoid deep dorsiflexion for insertional pain.

Any sharp pull at the Achilles attachment

Alfredson H, Pietilä T, Jonsson P, Lorentzon R. Heavy-load eccentric calf muscle training for the treatment of chronic Achilles tendinosis. American Journal of Sports Medicine. 1998;26(3):360–366.

Silbernagel KG, Thomeé R, Eriksson BI, Karlsson J. Continued sports activity, using a pain-monitoring model, during rehabilitation in patients with Achilles tendinopathy: a randomized controlled study. American Journal of Sports Medicine. 2007;35(6):897–906.

Chimenti RL, Neville C, Houck J, Cuddeford T, Carreira D, Martin RL. Achilles Pain, Stiffness, and Muscle Power Deficits: Midportion Achilles Tendinopathy Revision 2024. Journal of Orthopaedic & Sports Physical Therapy. 2024;54(12):CPG1–CPG32.

Walkito turns these Achilles exercises into a short plan for the 3, 5 or 7 days a week you pick, and a sore morning in your check-in makes that day’s session lighter. Doing it as a plan

Mid-tendon or at the heel bone: why it changes the exercise

Key findingIn a pilot study of 27 people with insertional Achilles pain, floor-level-only eccentric loading that avoided deep dorsiflexion gave good results in 67% of cases (Jonsson and colleagues, 2008).

Mid-portion Achilles tendinopathy sits in the body of the tendon, typically 2 to 6 centimeters above the heel bone. Standard eccentric drops over a step edge and heavy slow resistance have their best evidence here.

Side view of a foot and ankle showing the Achilles tendon running from the calf to the back of the heel bone, with a red area in the middle of the tendon.
Achilles tendon pain is usually in one of two places: the middle of the tendon, or where it attaches to the heel bone. Illustration: InjuryMap, CC BY 4.0, labels by Walkito

Insertional Achilles tendinopathy is pain right at the tendon-bone attachment. Deep dorsiflexion, bending the ankle so the toes come up toward the shin, compresses the tendon against the heel bone and irritates the insertion. In a 2008 pilot study of 27 people (34 tendons), floor-level-only eccentric loading, with no dorsiflexion past neutral, reported good results in 67 percent of cases.

If your pain is at the back of the heel bone, do all heel raises and heel drops at floor level and avoid aggressive stretching. This is the most important modification in Achilles programs, and the one most commonly missed.

Jonsson P, Alfredson H, Sunding K, Fahlström M, Cook J. New regimen for eccentric calf-muscle training in patients with chronic insertional Achilles tendinopathy: results of a pilot study. British Journal of Sports Medicine. 2008;42(9):746–749.

Chimenti RL, Neville C, Houck J, Cuddeford T, Carreira D, Martin RL. Achilles Pain, Stiffness, and Muscle Power Deficits: Midportion Achilles Tendinopathy Revision 2024. Journal of Orthopaedic & Sports Physical Therapy. 2024;54(12):CPG1–CPG32.

How much pain is okay during Achilles exercises?

Key findingIn a trial of 38 people, those who kept running with pain held to about 5 out of 10 and settled by morning improved as much at twelve months as those who rested first (Silbernagel and colleagues, 2007).

In Silbernagel 2007, 38 people with Achilles pain were split into two groups. One kept running and jumping during rehab, with pain during and after loading allowed up to about 5 out of 10, as long as it was back to its usual level by the next morning and did not worsen week over week. The other rested first. Both improved significantly at 12 months, with no difference between them.

The 5/10 figure is from one study, not a universal standard, but it is the most cited pain model in Achilles rehab. Walkito uses a 6/10 stop rule for heel pain on the plantar fasciitis page. Pain that does not settle overnight, worsens week to week, or arrives as a sudden sharp episode is the signal to back off.

Silbernagel KG, Thomeé R, Eriksson BI, Karlsson J. Continued sports activity, using a pain-monitoring model, during rehabilitation in patients with Achilles tendinopathy: a randomized controlled study. American Journal of Sports Medicine. 2007;35(6):897–906.

Does heavy slow resistance work as well as eccentric drops?

Key findingA 2015 trial of 58 people found that heavy slow resistance three days a week gave lasting results as good as the classic twice-daily eccentric protocol (Beyer and colleagues, 2015).

Yes, based on current evidence. A 2015 trial of 58 people compared heavy slow resistance (HSR), done 3 days a week, against the classic twice-daily eccentric protocol. The conclusion: "Both traditional ECC and HSR yield positive, equally good, lasting clinical results in patients with Achilles tendinopathy."

A 2021 network meta-analysis of 29 trials found no clinically relevant difference between any active exercise approach at 3 or 12 months. All were better than doing nothing. No trial was at low risk of bias. The authors recommended starting with a calf-muscle exercise program because it is low-cost and has few harms.

The protocol shape matters less than loading the tendon consistently. For the same calf-strengthening logic applied to heel pain under the foot, see calf raises for plantar fasciitis.

Beyer R, Kongsgaard M, Hougs Kjær B, Øhlenschlæger T, Kjær M, Magnusson SP. Heavy slow resistance versus eccentric training as treatment for Achilles tendinopathy: a randomized controlled trial. American Journal of Sports Medicine. 2015;43(7):1704–1711.

van der Vlist AC, Winters M, Weir A, et al. Which treatment is most effective for patients with Achilles tendinopathy? A living systematic review with network meta-analysis of 29 randomised controlled trials. British Journal of Sports Medicine. 2021;55(5):249–256.

Can you keep running while doing Achilles rehab?

In Silbernagel 2007, patients who kept running under the pain-monitoring model did not do worse than those who rested first. The trial concluded that continued, pain-monitored activity "might therefore represent a valuable option" during rehab.

That does not make running harmless in every case. If pain does not settle overnight, or if each week is worse, back off. Pain at the heel-bone attachment needs more caution than mid-tendon pain. Any sudden pop or snap is a reason to stop and see a clinician. Running load management is covered on heel pain for runners.

Silbernagel KG, Thomeé R, Eriksson BI, Karlsson J. Continued sports activity, using a pain-monitoring model, during rehabilitation in patients with Achilles tendinopathy: a randomized controlled study. American Journal of Sports Medicine. 2007;35(6):897–906.

How long do Achilles exercises take to work, and how do you track it?

Recovery from Achilles tendinopathy is measured in months. The core loading trials ran programs for about three months and tracked outcomes to 12 months. The 2024 guideline notes functional improvement can appear by 2 weeks, but fuller recovery extends well beyond that, and insertional cases tend to take longer than mid-portion.

The guideline names the single-leg heel-rise endurance test as a way to track calf strength. A normative study of 566 healthy adults puts the typical count at about 23 to 24 repetitions, adjusted for age, sex and activity level. What matters is the trend over time and the gap between your two sides. The calf goal in the app is 25 single-leg calf raises, tested every 14 days while the goal is active, then every 28 days.

Chimenti RL, Neville C, Houck J, Cuddeford T, Carreira D, Martin RL. Achilles Pain, Stiffness, and Muscle Power Deficits: Midportion Achilles Tendinopathy Revision 2024. Journal of Orthopaedic & Sports Physical Therapy. 2024;54(12):CPG1–CPG32.

Alfredson H, Pietilä T, Jonsson P, Lorentzon R. Heavy-load eccentric calf muscle training for the treatment of chronic Achilles tendinosis. American Journal of Sports Medicine. 1998;26(3):360–366.

Beyer R, Kongsgaard M, Hougs Kjær B, Øhlenschlæger T, Kjær M, Magnusson SP. Heavy slow resistance versus eccentric training as treatment for Achilles tendinopathy: a randomized controlled trial. American Journal of Sports Medicine. 2015;43(7):1704–1711.

Silbernagel KG, Thomeé R, Eriksson BI, Karlsson J. Continued sports activity, using a pain-monitoring model, during rehabilitation in patients with Achilles tendinopathy: a randomized controlled study. American Journal of Sports Medicine. 2007;35(6):897–906.

Hébert-Losier K, Wessman C, Alricsson M, Svantesson U. Updated reliability and normative values for the standing heel-rise test in healthy adults. Physiotherapy. 2017;103(4):446–452.

Questions people ask

What are the best eccentric exercises for Achilles tendon pain?

Eccentric heel drops are the most studied exercise for Achilles tendon pain: rise on both feet, shift to the sore leg, lower slowly over three seconds with the heel sinking below the step. In a 1998 trial, 15 athletes doing this twice daily for three months all returned to their prior running level. Heavy slow resistance did equally well later.

How many eccentric heel drops should you do?

The original Alfredson protocol was 3 sets of 15 heel drops, twice a day, 7 days a week, for three months, done with both a straight and a bent knee. Walkito starts at 3 sets of 10 on each leg. A 2015 trial found heavy slow resistance 3 days a week gave equally good, lasting results.

How much pain is okay during Achilles exercises?

One trial allowed pain up to about 5/10 during loading, provided it settled by the next morning and did not worsen week to week. Patients under that model did as well as those who rested first (Silbernagel 2007). Pain that stays elevated overnight or worsens weekly is the signal to back off.

Are insertional Achilles exercises different?

Yes. The standard deep heel-drop protocol had poor results for pain at the heel-bone attachment. A 2008 pilot study tested floor-level-only eccentric loading, no dorsiflexion past neutral, and reported good results in 67 percent of 27 patients. Deep drops and aggressive stretching should be avoided for insertional pain.

How long do Achilles tendonitis exercises take to work?

Recovery is measured in months. The core trials ran loading programs for about three months, tracking results to 12 months. The 2024 guideline notes functional improvement can begin by 2 weeks, but fuller recovery extends well beyond. No trial promises a fixed timeline, and insertional pain tends to take longer.

What should you not do with Achilles tendonitis?

Avoid sudden jumps in running volume or sprint intensity, deep calf stretching if your pain is at the heel-bone attachment, and pushing through pain that stays elevated the next morning or worsens week to week. A sudden pop or snap needs a clinician right away. Complete rest is not required; pain-monitored activity is usually better.

See a clinician first if

  • you felt a sudden pop, snap or a sensation of being kicked in the back of the leg, especially with immediate difficulty pushing off or walking on the toes. This can indicate an Achilles tendon rupture
  • you are currently taking or have recently taken a fluoroquinolone antibiotic (such as ciprofloxacin or levofloxacin) and have new or worsening tendon pain. These drugs carry an FDA boxed warning for tendinitis and tendon rupture
  • pain and swelling came on suddenly with fever, redness or warmth over the tendon
  • there is significant swelling, bruising or a palpable gap in the tendon
  • pain is right at the heel-bone attachment and gets worse with stretching or deep heel drops, not better. This points to insertional tendinopathy needing a modified approach or a clinician's input
  • pain or stiffness is getting steadily worse over weeks despite consistent loading
  • pain is present at rest or wakes you at night
  • you cannot put weight on the foot or you are limping

Doing it as a plan

You don't have to guess the order, the doses or when to add load. Walkito builds a plan one week at a time around one goal. The calf chain runs from seated raises through double-leg raises, a hold, towel raises, eccentric heel drops and pogo hops. Each step opens once two sessions at the current level felt easy.

Every 14 days (then every 28 once the calf goal is reached), a test checks calf endurance and balance. Walkito is an exercise program. It does not diagnose. If pain is right at the heel-bone attachment, have a clinician check it before you load it hard.
